Product introduction
BT89 it is a 8.0 inch IP67 Rugged tablet with option modules 1D/2D barcode scanner,NFC reader,built in UHF RFID ,125k/134.2 LF RFID,we use Corning Gorilla tempered glass touch panel and double injection mould housing to make it shockproof and sealed completely to make it waterproof,and the model with Octa core CPU and Android 7.0 o.s,with dual band WIFI,Bluetooth 4.0 and 2G/3G/4G etc wireless technology,Meanwhile the model with 5.0M front camera and 13.0M rear one,the most important with built in 8000mah big battery to make it continuously working 10-14 hours,
And there are type C,Type A etc ports,And we also design handstrap to better hold the device,in futures cradle for better charging our customers they mainly use the devices in warehouse management,animal management and some install their own Application to control special projects
The main features
◪ 8.0 inch IP67 1280*800 above 400 nits brightness display
◪ Corning Gorilla tempered glass and Double injection mould for better protection
◪ Octa core Android 7.0 o.s 2GB RAM and 16GB ROM or 3GB+32GB
◪ Dual band WIFI,Support GPS navigation
◪ Front 5.0M and rear 13.0M camera
◪ 8000mah big battery for long time working
◪ Honeywell N6603 1D/2D Barcode scanner
◪ Built in UHF RFID
◪ Built in LF RFID 125/134.2K
◪ NFC reader
Product details
Product details
8.0 inch IP67 Rugged tablet with UHF RFID,LF RFID,NFC reader,1D/2D Barcode scanner BT89 | ||
Physical Parameters | Weight | 650g(including battery) |
Size | 242*129*21mm | |
Basic | CPU | MTK6753 Octa-core 2.0GHz |
Memory | 2GB RAM + 16GB ROM | |
OS | Android 7.0 | |
Display | Gorilla Glass 3 9H 8.0 inch TFT-LCD(800x1280)touch screen with backlight | |
Touch Screen | 5 point touch | |
GSM | 850/900/1800/1900MHz | |
WCDMA | 850/1900/2100MHz | |
LTE | FDD-LTE Band 1, 2, 3, 4, 7, 17, 20;TDD-LTE Band 38, 39, 40, 41 | |
Camera | 5.0MP Front + 13.0MP Camera, Auto-focus with LED flash | |
WIFI | 2.4GHz/5.8GHz Dual Frequency, IEEE 802.11 a/b/g/n | |
Bluetooth | Bluetooth Class v2.1+EDR, Bluetooth v3.0+HS, Bluetooth v4.0 | |
GPS | GPS(embedded A-GPS), accuracy of 5 m | |
Battery | 8000mAh | |
Standby Time | 720 hours | |
Charging Time | < 5 hours | |
RFID | Ultra High Frequency | Built-in 1.5m for EPC C1 GEN2 / ISO18000-6 - c protocol of 860-960MHZ tag read operation |
High frequency | 0 - 7 cm range for ISO15693, ISO14443A double deal 13.56 MHz tags for reading and writing | |
Low frequency | 125 K / 134.2 K animal ear tag （Mifare Classic） | |
NFC (NXP547) | Frequency | 13.56MHz |
Baud Rate | 9600-115200 bits/s | |
Support Protocol | ISO/IEC 14443A/B/15693 | |
Support Card | Mifare One S50/Ultralight/One S70/Pro, Ntag203, AT88RF020, 66CL160S, SR176, SRIX4K, I-code 1/2, TI RFID Tag-it HF-I, EM4135, EM4034 | |
1D Barcode | Module | Honeywell N4313 |
Support | Code 39, Code 93, Code 128, Code bar, EAN-13, EAN-8, UPC-A, UPC-E, ITF 14, UCC/EAN-128, ITF 25, Matrix 25, EAN-128, ISBN | |
Read distance | 0 cm - 50 cm | |
Read Speed | 104 ± 12 scans/S | |
First read rate | > 99% | |
Error rate | < 0.01% | |
false reject rate | < 0.01% | |
QR code scanner | Honeywell-6603 | Software decoding - error rate < 0.01% |
2D Code | PDF417, MicroPDF417, MaxiCode, Data Matrix, QR Code, Aztec, Aztec Mesa, Code 49, UCC Composite | |
1D Code | Code 39, Code 128, Codabar, UPC, EAN, Reduced Space Symbology, Code 93, Codablock | |
Postal Code | Postnet (US), Planet Code, BPO 4 State, Canadian Post, Japanese Post, KIX (Netherlands) Post | |
Active in Close Communication | Active 2.45G | Distance is 80m, can be read all at once |
433 | Can Read more than 80m distance(Adjustablet) | |
Development Environment | ||
SDK | HHW Software Development Kit | |
Language | Java | |
Environment | Android Studio or Eclipse | |
Accessories | ||
Accessories | Standard | 1xPower Supply; 1xLithium Polymer Battery; 1xDC charging cable; 1xUSB data cable |
Optional accessories | ||
Environment | Operating temperature | (-20℃) - (50℃) |
Storage temperature | (-20℃) - (70℃) | |
Relative humidity | 10% - 90%RH | |
Application scene
Security check
Warehouse management
logistics industry
Industry
Product Certification
BT89
BT89
